Customer drawing to control plan
Turns a customer's engineering drawing into a finished control plan (what gets inspected, how, how often, and with which gage) in the shop's own format.
The problem
Every new part number needs a control plan. A quality engineer builds each one by hand from the customer's drawing and a process risk analysis, hours per part, and every customer marks critical dimensions differently. The backlog was about to force four new quality hires.
Why Structify, not an off-the-shelf tool
Generic document AI can read a drawing. It can’t know which gages are on your shelf, which features your customer calls critical, or what format your customer’s auditor expects. Structify builds the plan from your rules and delivers it in your format.
- Built for
- Precision machining and job shops; aerospace and defense
- Connects to
- Customer prints (PDF, DWG, STEP) · QMS (HyperRay, ProShop, Sightline) · gage library
How it works · Four modules, each can ship on its own
- 01
Drawing reader
Pulls every dimension, tolerance, note, and flagged critical characteristic off the PDF or CAD print, including scans and prints that chain to customer standards.
- 02
Shop rules engine
In the catalog - 03
Self-check
In the catalog - 04
Format-true export
In the catalog
Start here
Live in 14 days.
Which module to ship first, and what we need from you.
